Nrog rau qhov muaj koob meej ntawm drone thev naus laus zis, qhov teeb meem ntawm qis -qhov siab qhov siab tau txais kev saib xyuas ntau dua. Thiab drone nrhiav thiab tso cov cuab yeej siv tau dhau los ua lub zog tseem ceeb hauv kev ua kom muaj kev ruaj ntseg qis - qhov siab. Lub handheld drone nrhiav kom pom thiab tso cov cuab yeej, ua tus thawj coj hauv daim teb no, cov thev naus laus zis tseem ceeb tom qab nws yog tus yuam sij kom ua tiav qhov tseeb thiab qhov chaw.
Ua ntej, cov khoom tseem ceeb hauvlub handheld drone nrhiav kom pom thiab tso cov khoom siv- VCO
VCO (Voltage-Controlled Oscillator) yog lub hauv paus tseem ceeb hauv RF Circuit Court, uas tuaj yeem kho cov teeb liab tawm zaus raws li qhov hloov pauv ntawm cov khoom siv hluav taws xob, yog li ua rau kev ntes UAV cov teeb liab hauv ntau zaus. Nyob rau hauv lub handheld drone detection thiab positioning cov cuab yeej, tag nrho RF pem hauv ntej -kawg architecture nyob rau hauv VCO tau sai thiab meej scan lub dav zaus band ntawm 100MHz mus rau 6GHz, tsis plam tej yam ua tau UAV teeb liab, muab nplua nuj raw cov ntaub ntawv rau tom ntej no teeb liab ua thiab tsom xam.
Thib ob, nyob rau hauv lub teeb liab nrhiav pom thiab txheeb xyuas theem, lub handheld drone nrhiav kom tau thiab muab tso rau cov cuab yeej siv advanced spectrum detection technology.
Kev tshawb nrhiav spectrum technology, los ntawm kev tshuaj xyuas cov electromagnetic spectrum nyob rau hauv qhov chaw, tuaj yeem txheeb xyuas cov yam ntxwv tshwj xeeb uas tawm los ntawm ntau hom drones. Rau cov qauv zoo li DJI, txij li lawv cov teeb liab muaj cov qauv spectral ruaj khov, kev ntes cov drone ntes thiab cov cuab yeej siv tau sai sai thiab txheeb xyuas lawv los ntawm kev tsim - hauv database. Rau cov drones hauv tsev xws li cov ya los ntawm cov teeb meem, lossis cov khoom siv WiFi, lawv cov teeb liab yuav nyuaj dua thiab sib txawv. Txawm li cas los xij, handheld drone nrhiav kom pom thiab tso cov khoom siv, nrog rau lawv cov teeb liab muaj peev xwm ua tau zoo, tuaj yeem tshem tawm cov yam ntxwv ntawm cov drones los ntawm qhov nyuaj electromagnetic ib puag ncig thiab txheeb xyuas lawv. Tshwj xeeb tshaj yog nyob rau hauv kev tshawb nrhiav FPV, cov cuab yeej tuaj yeem ntes thiab txheeb xyuas qhov tsis sib xws ntawm FPV nyob kis tau tus mob (frequency point, bandwidth, protocol features), uas tso siab rau qhov tseeb capture thiab ceev ceev decoding technology ntawm kis tau tus mob ntawm lub drones. Qhov no ua rau cov neeg ua haujlwm ruaj ntseg nkag siab txog qhov xwm txheej dav hlau thiab thaj chaw ntawm lub zeem muag ntawm cov drones, thiab ntxiv dag zog rau kev tswj hwm lub peev xwm rau cov drones tshwj xeeb no.
Thib peb, cov cuab yeej muab tso rau qhov tseeb yog lwm qhov tseem ceeb ntawm qhov zoo ntawm cov khoom siv tes tuav drone nrhiav thiab muab tso rau cov khoom siv. Nws ua rau qhov tseeb qhov chaw ntawm ob lub tsheb tsis muaj neeg tsav dav hlau thiab tus neeg teb xov tooj (cov chaw taws teeb tswj chaw taws teeb).
Nyob rau hauv cov nqe lus ntawm drone positioning, cov cuab yeej xam qhov tseeb txoj hauj lwm ntawm lub drone los ntawm kev tau txais cov video kis tau tus mob signals thiab tswj cov teeb liab xa los ntawm drone, thiab nthuav nws nyob rau hauv daim ntawv ntawm ib tug "drone icon" nyob rau hauv lub electronic map interface. Rau DJI series drones uas siv OcuSync video kis tau tus mob txoj kev, lub handheld detection thiab positioning cov cuab yeej tuaj yeem txhim kho qhov chaw raug ntxiv los ntawm kev siv cov yam ntxwv ntawm kev sib kis no. Nyob rau hauv cov nqe lus ntawm qhov chaw tsav tsheb, cov cuab yeej tau txais cov kev tswj cov teeb liab xa los ntawm cov chaw taws teeb tswj thiab siv cov txheej txheem kev ua haujlwm siab tshaj plaws los txiav txim siab txoj hauj lwm ntawm tus tsav, thiab qhia nws nyob rau hauv daim ntawv ntawm "cov chaw taws teeb tswj icon" ntawm daim ntawv qhia hluav taws xob. Tsis tas li ntawd, cov cuab yeej tseem muaj lub luag haujlwm rau kev tsav tsheb, uas tuaj yeem npaj txoj kev tshawb nrhiav raws li tus tsav txoj haujlwm thiab muab "ib qho- nyem txoj haujlwm navigation". Kev ua tiav ntawm txoj haujlwm no yuav tsum tau muab cov ntaub ntawv tso rau hauv daim ntawv qhia kev siv tshuab kom paub meej tias cov neeg ua haujlwm ruaj ntseg tuaj yeem nrhiav tau tus tsav txoj haujlwm sai thiab raug.
Plaub, cov cuab yeej tshwj xeeb tshwj xeeb kuj yog ib qho tseem ceeb ntawm cov cuab yeej siv thev naus laus zis ntawm kev tuav tes drone nrhiav kom tau thiab cov cuab yeej siv.
Rau cov drones ntawm DJI series uas siv OcuSync, cov cuab yeej tuaj yeem paub txog lawv cov cim cim tshwj xeeb. Rau RID raws tu qauv drones, los ntawm kev tshuaj xyuas lawv cov cim RID, cov cuab yeej tuaj yeem tau txais tus lej cim tshwj xeeb (SN) thiab lwm yam ntaub ntawv tus kheej ntawm cov drones. Rau lub wifi drones, SN code tuaj yeem raug rho tawm. Kev ua tiav ntawm cov thev naus laus zis no yog nyob ntawm - kev tshawb fawb tob thiab kev tshuaj xyuas ntawm kev sib txuas lus ntawm ntau hom drones. Cov cuab yeej tau nruab nrog ntau txoj cai parsing modules, uas tuaj yeem ceev thiab raug tshem tawm cov ntaub ntawv tus kheej los ntawm drone signals, muab lub hauv paus tseem ceeb rau kev taug qab thiab kev saib xyuas ntawm cov drones, thiab tiv thaiv kev tsis qhia npe thiab kev ua phem ntawm kev ua txhaum cai ntawm drones.
Thib tsib, nyob rau hauv kev ua haujlwm ntawm ntau- lub hom phiaj saib xyuas thiab kev taug qab cov thev naus laus zis, cov cuab yeej nqa drone tshawb pom thiab cov cuab yeej siv tau pom tau tias muaj peev xwm zoo tshaj plaws.
Nyob rau qee qhov xwm txheej, cov cuab yeej muaj peev xwm ua kom pom tau ntau dua lossis sib npaug rau 10 lub dav hlau tsis muaj neeg siv. Qhov no yuav tsum tau ua cov teeb liab ua tau zoo thiab muaj peev xwm tuav tau cov ntaub ntawv, ua kom muaj kev sib txuas ua ke ntawm ntau lub drone signals kom tsis txhob cuam tshuam thiab tsis meej pem ntawm lawv. Nyob rau hauv cov nqe lus ntawm trajectory mus txog qhovtwg, cov cuab yeej tsis tu ncua tau txais txoj hauj lwm teeb liab ntawm lub drones, cov ntaub ntawv thiab khaws cia lawv, thiab ces qhia lub davhlau trajectories ntawm lub drones ntawm lub electronic map interface nyob rau hauv lub sij hawm. Nyob rau tib lub sijhawm, cov cuab yeej tseem txhawb nqa kev ua haujlwm ntawm keeb kwm trajectory playback, uas yuav tsum tau txhim khu kev qha cov ntaub ntawv khaws cia technology thiab cov ntaub ntawv siv tau zoo los xyuas kom meej kev khaws cia ua tiav thiab ceev rov qab cov ntaub ntawv keeb kwm ya davhlau, kom cov neeg ua haujlwm ruaj ntseg tuaj yeem txheeb xyuas txoj kev ya davhlau ntawm drones thiab txheeb xyuas cov kev nyab xeeb thiab cov qauv.
Thib rau, ntxiv rau, qhov system ua haujlwm ib puag ncig thiab kho vajtse teeb tsa ntawm cov cuab yeej nqa drone tshawb pom thiab cov cuab yeej tso tawm kuj tseem muaj kev txhawb zog rau kev siv cov thev naus laus zis tseem ceeb.
Cov cuab yeej siv Android 12 kev ua haujlwm, uas muaj kev ruaj ntseg zoo thiab ua tau zoo, muab lub platform du rau kev ua haujlwm ntawm ntau yam kev siv thiab algorithms. Kev teeb tsa ntawm 8GB nco thiab 256GB cia kom ntseeg tau tias lub cuab yeej tuaj yeem ua cov ntaub ntawv ntau ntawm cov teeb liab thiab khiav cov txheej txheem nyuaj, thaum tseem tuaj yeem khaws ntau cov ntaub ntawv tshawb pom thiab cov ntaub ntawv keeb kwm. Lub 6-inch loj kov npo muaj qhov kev daws teeb meem siab ntawm 2160 * 1080 pixels, muab cov neeg siv nrog kev ua haujlwm meej thiab cov ntaub ntawv tso saib interface, ua kom yooj yim rau lub sijhawm saib ntau yam ntaub ntawv ntawm lub dav hlau tsis muaj neeg siv thiab khiav cov khoom siv.
Xya, Xaus
Lub handheld drone detection thiab positioning equipment integrates the core technologies xws li tag nrho cov architecture ntawm VCO xov tooj cua zaus pem hauv ntej -kawg, spectrum detection, meej positioning, cim tus kheej paub, multi- phiaj saib xyuas thiab trajectory taug qab. Ua ke nrog kev txhim kho kho vajtse siab heev thiab software system, nws ua tiav kev tshawb pom tseeb thiab qhov chaw ntawm lub dav hlau tsis muaj neeg siv. Kev sib koom ua haujlwm ntawm cov thev naus laus zis no ua rau cov cuab yeej siv tau zoo thiab raug saib xyuas cov kev hloov pauv ntawm lub dav hlau tsis muaj neeg tsav tsheb nyob rau hauv ib puag ncig electromagnetic complex thiab ntau yam kev thov, muab kev txhawb nqa khoom rau qis- qhov chaw siab nyab xeeb ua haujlwm thiab muab cov ntaub ntawv muaj txiaj ntsig zoo rau kev txhim kho thev naus laus zis hauv kev saib xyuas lub dav hlau tsis muaj neeg siv.
Peb yogib lub chaw tsim khoom hauv Suav teb tshwj xeeb hauv kev kho cov khoom siv tes tuav drone nrhiav kom pom thiab tso cov khoom sivrau kev cuam tshuam thiab thaiv. Peb muab ntau yamhandheld drone nrhiav kom pom thiab tso cov khoom sivrau koj xaiv los yog customize. Yog tias koj muaj kev xav tau, thov hu rau peb ntawminfo@alasartech-security.com.
