DDS Hwj Chim Jammer







Khoom Taw Qhia

Waterproof Lub Zog Hluav Taws Xob DDS Jamming System Aat - DDS tshwj xeeb rau hauv tsev loj cuj, xws li kev teeb tsa tub rog thiab tsoomfwv cov tebchaw. Nws raug txhim kho los ntawm peb lub tsev loj cawg jamming system Aat {}} DDS202PJ. Qhov kev xav pom kev tuaj yeem tswj hwm remotely nrog kev ua kom muaj zog thiab deactivation ntawm lub system. Nws yog nqa tawm tsuas yog siv Is Taws Nem lossis Ethernet los ntawm lub khoos phis tawj hauv nruab nrab.

Aat - DDS202PJ tau tsim tsa ob lub tshuab hluav taws xob zoo nkauj, uas ua rau lub zog ua haujlwm "ntse / 24 teev / 7 hnub tsis tu ncua txawm tias huab cua kub. Nws cov kev nyab xeeb tsim kom ua kom muaj txiaj ntsig tias lub tsev loj cuj tsis tau ua rau lub tsev loj cuj tsis tau nrog lub kaw lus, nws ua haujlwm nrog xauv thiab tus yuam sij.











Khoom nta
1. Txais cov txheej txheem tshiab Digital syntheser teeb liab kev teeb hluav taws xob lossis cov chaw tso zis tawm ntawm cov chaw taws teeb tsis pub dhau ib qho kev xaiv tau raug xaiv los thaiv.

2.Qhov yog tsim nyog siv rau hauv lub teeb liab PC, LAN teeb nws yog cov chaw taws teeb tswj hwm thiab Centralized, kev tswj hwm lub platform;

3. RJ45 Whed cov chaw taws teeb tswj hwm lossis cov ntaub ntawv wireless

4. Tiag- lub sijhawm saib xyuas kev ua haujlwm;

5. Sau cov lus nug. Log nug;

6. Txhawb txhua lub zog band hloov tau.

7. Txhawb txhua band tuaj yeem zoo -} tuned nyob rau hauv tsawg zaus ntau

8. Txhawb nqa gis daim ntawv qhia kev ua haujlwm, yooj yim rau xauj thiab cov lus nug.

9. Txoj cai tswj hwm kev tswj hwm, tuaj yeem tsim cov qib sib txawv browser;

10. Jammer Cov Txhaum Lub cev, thiab tuaj yeem xa email, ceeb toom cov ntaub ntawv ceeb toom;

11. Txhawb kev saib xyuas hauv zos thiab chaw taws teeb, nws yog qhov haum rau thaj chaw hauv zos network

12. Email thiab Alarming System, thaum muaj qee yam tsis raug, RF Cable txiav tawm txhob txwm txiav tawm, teeb meem kub.

13. Teem lub sijhawm qhib thiab kaw lub tshuab, system tuaj yeem siv tsis siv neeg nkag mus ua haujlwm.

14. Txhua tus qauv uas tuaj yeem yog rau / tawm thiab ua haujlwm sib cais.

15. Xaiv cov kav hlau txais xov los muab kev yooj yim ntxiv hais txog Jamming Kev Them Nyiaj

16. Sab hauv npo rau kev tswj hwm hauv ib cheeb tsam, kom tswj tau yooj yim thiab txij nkawm.

17. Kev sib koom ua ke nrog tus thib peb.

18. Perpetual Daim Ntawv Tso Cai

19. Tswj Center software uas tsis muaj Jammers tus naj npawb txwv los tswj thiab tswj hwm.









Kev Ntsuas Cov Qauv:

Yam	Chaw ua uas tsis tau haus
Hov ntau	Ch 1 758-803 mhz 100W Ch 2 851-894 mhz 100W Ch 3 1930-1990 mhz 100W Ch 4 2110-2180 mhz 100W Ch 5 2620 -2690 mhz 100W Ch 6 3300-3600 mhz 100W
RF tso zis ntau (watt)	600W
Kev siv fais fab	2200va
Lub zog muab hluav taws xob	220vac / 110VAC, DC 24-27V (1 fais fab mov los ntawm 1 module)
Jamming nrug	150-500m (nyob ntawm ib puag ncig teeb tsa lub zog), qhov zoo dua xaiv cov kav hlau txais xov xwm, tiv thaiv kev tiv thaiv zoo dua. )
Hov ntau	Txhua band tuaj yeem zoo -} tuned nyob rau hauv ib qho kev txwv tsawg Kev them nyiaj yug teeb tsa 4 ntu zaus
Fais fab hloov kho	Txhua tus band tuaj yeem kho lub zog los ntawm software.
Tsev nyob	Daim xaim
Cov chaw taws teeb tswj	RJ45
Ntaus Cov Ntaus Loj	720 * 450 * 420 hli
Tag nrho qhov hnyav	60kg
Tswjhwm system	LAN tswj los ntawm software
Jamming Qhov	Direct Digital Digital Synthesize (DDS) Technology
Kev vaum	5%~80%
Kev Kub Ntxhov	-40 Qib ~ {+65 degree
Kev Cua Txias	Nquag ntse nrog kev nkag ua ntej nkag
LOJ DEJ	Ms66
Lub kav hlau txais xov hom	Tus kav hlau txais xov Directional los yog Omni kav hlau txais xov

Khov thiab lwm qhov chaw loj rhiab xws li tub rog lossis tsoomfwv cov tebchaw. Nws tseem tuaj yeem siv hauv cov roj thiab cov chaw ua haujlwm roj av, cov kev ruaj ntseg, cov kev pabcuam kev saib xyuas, tsev cia puav pheej, tsev khaws ntaub ntawv, tsev khaws ntaub ntawv, thiab lwm yam.



RJ45 LAN Cov Chaw Taws Teeb Tsuj Topology:

Wireless chaw taws teeb tswj sab topology:





Npog cov kev taw qhia installation kos duab:





Cov hau kev qhia: Npog raws li cov kev taw qhia ntawm tus liab liab, thiab tom qab ntawd kho lub kaum sab xis yuav tsum raug txiav txim siab raws li lub xaib teeb tsa thiab debugging).

Hauv cov ntawv thov engineering, tus tswv tsev thiab kav hlau txais xov ntawm waterproof thiab tuaj yeem ntsia ncaj qha hauv chaw sab nraum zoov:

1. Xaiv Directional kav hlau txais xov (phaj) raws li lub vev xaib;

2, txhawm rau kom ua tiav cov kev tiv thaiv kev zoo tshaj plaws, nws raug pom zoo kom ntseeg tau tias tsis muaj chaw nres tsheb nyob hauv 300 meters nyob ib ncig ntawm lub installation;

3, tuaj yeem ntsia los ntawm lub ru tsev ntawm lub tsev, phab ntsa sab nraud lossis lub teeb ncej;
