Khoom Taw Qhia
Lub xov tooj ntawm tes puv -frequency code detection system yog ib yam khoom tshwj xeeb uas tsim los rau pej xeem kev ruaj ntseg thiab kev ruaj ntseg hauv teb chaws thiab lwm qhov chaw tshawb nrhiav. Nws tuaj yeem tswj hwm qee qhov chaw tseem ceeb thiab siv cov cuab yeej cuab tam los sau cov xov tooj ntawm tes IMSI (kev txheeb xyuas cov neeg siv xov tooj thoob ntiaj teb) yam tsis muaj ntawv ceeb toom. Cov lej cim, cov ntawv cim tshwj xeeb nrog SIM daim npav xov tooj ntawm tes, IMEI, qhov chaw, thiab cov ntaub ntawv sijhawm raug tshuaj xyuas los ntawm sab nraub qaum -kawg software system thiab muab piv nrog cov npe dub los txiav txim qhov chaw tshwj xeeb ntawm tus neeg raug liam thiab nqa ntau qhov tseeb thiab raug rau kev tshawb nrhiav haujlwm. Nws yog txoj kev yooj yim rau kev daws teeb meem txhaum cai.
Khoom Feature
1. Full -txoj kab hluav taws xob.
GSM, CDMA, TD-SCDMA, WCDMA/LTE (tus thawj coj hauv kev lag luam hauv kev txhawb nqa 4G ncaj qha hluav taws xob laj kab), nws txhawb ntau- zaus hauv ib lub tshuab.
2. Tsis siv neeg cheb
Tsis siv neeg cheb tawm cov ntsiab lus zaus thiab PCI qhov tseem ceeb ntawm thaj chaw lub hom phiaj, siv cov PCI sib txawv ntawm tib zaus taw tes kom txo qis kev cuam tshuam, tsis txhob tsa lub suab nrov ntawm qhov chaw nres tsheb macro, thiab cia li pom qhov kev hloov pauv ntawm cov xov tooj txawb ib puag ncig.
3. Kev sau ceev ceev
Ceev nrooj ntes tsis pub dhau 1,000 meters tag nrho los ntawm lossis nyob twj ywm cov ntaub ntawv qhia tus neeg siv xov tooj ntawm tes (qhov kev ncua deb yog cuam tshuam nrog ib puag ncig thiab xa hluav taws xob).
4. Kev sau ua haujlwm siab
Tsis siv neeg synchronization ntawm lub hauv paus chaw nres tsheb moos, kev ua haujlwm siab thiab qhov tseeb ntawm cov laj kab hluav taws xob.
5. Kho lub zog
Muaj peev xwm tswj tau kev pab them nqi thiab kev sau cov ntaub ntawv ntau yam.
Specificaiton
Qhov System Parameter | |
Ua hauj lwm Standard | GSM / 900M / 1800M / band38, band39, band40, band41 / band1, band3 |
Hloov Hwj chim | 1W, 5W, 10W, 15W, 20W (ua - hauv amplifier, tuaj yeem kho tau) |
Carrier Combination | 4G LTE Carrier, Tuam Tshoj Mobile 2 Carriers thiab 1 txhua tus neeg nqa khoom rau Tuam Tshoj Unicom thiab Telecom. |
Ib 2G GSM Carrier rau Tuam Tshoj Txawb thiab Unicom | |
ACPR | -45/-50dBc |
EVM | Siab dua 6 feem pua |
Tawm -band Emission | Ntsib 3GPP |
Txais rhiab heev | -104dBm |
Txais dynamic ntau yam | -30dbm-104dbm |
Kev pab them nqi | 800meter (muaj feem xyuam rau ib puag ncig wireless thiab xa hluav taws xob) |
Capture Peak tus nqi | 800 pawg / min / carrier |
Nruab Nrab Capture Rate | >95 feem pua |
Fast Tsiv Capture Rate | >90 feem pua, 120KM/H |
Lub Sijhawm Rov Qab | <> |
Kav hlau txais xov thiab Interfaces | Omni/directional (yeem) |
Capture Interval | Nws tuaj yeem teem sijhawm (1min.-12hours) |
Kev xa cov ntaub ntawv | 3G Network / Cable (xaiv) |
Ceev ceev | 1800 yam khoom / min. (ib qhov chaw ntawm tus nqi siab tshaj) |
Kev cuam tshuam qhov system | Qhov cuam tshuam rau kev sib txuas lus ib txwm ntawm lub davhlau ya nyob twg hauv lub xeev standby:<30> |
Siv Txoj Kev | Tsau installation / tsheb -mounted / sab hauv tsev installation |
Fais fab mov | 220V |
Kev noj haus | GSM<80w,4g all="" band="" working="" 125w/standby="" 45w="" (power="" amplifier="" shut=""> |
IP | IP65 |
Qhov hnyav | <20kg (related="" to="" transmit=""> |
Khoom siv | Tuag-Aluminium |
Qauv | Cov kab noj hniav puv puv passive txias |
Sab nraud Interface | 1 10/100M Ethernet chaw nres nkoj, AV220V fais fab mov interface, RF kav hlau txais xov interface, rov qab kav hlau txais xov interface, GPS kav hlau txais xov |
Ua haujlwm Temp. Cov av noo | Ua haujlwm temp. -40-55 ° C |
Bandwidth (1 thib ob ntes 100 No.) | 10M |
Input voltage | AC 110V-300V |
System Main Functions
1. Ultra-kev kub ceev
IMSI, IMEI, TMSI siab-ceev peb-code tau txais
2. Rov qab tiv thaiv
Txhawb nqa xaim / wireless xa rov qab
3. Kev Tiv Thaiv Cov Ntaub Ntawv
Txhawb encrypted cia ntawm cov ntaub ntawv sau thiab cov ntaub ntawv hauv zos
4. Blacklist
Txhawb cov neeg siv kom ntes lub tswb thiab kev txwv kev sib txuas lus, txhawb nqa rov qab- tswb tswb thiab luv- cov lus ceeb toom
5. Cov lus nug ntse
Txhawb kev sib tsoo lus nug, nrog rau cov lus nug, taug qab playback, tsom xam neeg nyob, GPS qhia qhov chaw
6. Tswb kom sai
Txhawb lub tswb tsis ua haujlwm, siab- lub tswb nrov, lub tswb nrov nrov, tshaj- lub tswb nrov, lub zog- tswb tsis ua haujlwm, xov tooj cua- zaus kaw lub tswb, thiab lwm yam.
7. Kev tu yooj yim
Kev tswj chaw taws teeb tswj, hloov kho software
Txoj Cai Ua Haujlwm
1. System Block Diagram
2. Txoj Cai Ua Haujlwm
The mobile phone full-frequency code detection device simulates the broadcast-inducing signal of the operator's mobile communication network (china mobile/ Unicom/Telecom and later it can upgrade to another ), so that mobile phone terminals in the standby state where are around them will detect a change in the location area, thereby initiate a location area update process. The mobile terminal register and report IMEI/IMSI to the mobile code detect device, then it complete the collection of public network user terminal information in the coverage area, and then transmit the collected IMSI or IMEI in real time through wired or wireless backhaul. Background information collection center, the user can connect to the collection center through the client software and background management system to view the collected mobile terminal information in real time.
