Handheld Drone Locator





1, Txheej txheem cej luam

AAT-H2L-D Pro Pro yog lub cim tshiab ntawm tes tuav drone nrhiav thiab tso cov cuab yeej, txhim kho lub peev xwm FPV drone nrhiav tau. Nws tuaj yeem kuaj pom qhov qis- zaus sib tw drones thiab txiav txim siab lawv thawj- neeg caij dav hlau pom cov duab.

Cov khoom no suav nrog kev tshawb nrhiav drone spectrum, kev soj ntsuam raws tu qauv, kev txheeb xyuas RID, thiab lwm yam kev tswj hwm kev ua haujlwm rau hauv ib chav, nrog rau ib qho chaw nqa tau yooj yim -unit hnyav li ntawm 650g. Nws tuaj yeem ua tiav tiag tiag- lub sijhawm tshawb pom thiab ceeb toom ntxov rau 900 series drones, nrhiav kom raug thiab taug qab cov drones thiab lawv cov neeg ua haujlwm (cov chaw taws teeb tswj). Tus qauv tsim yog compact thiab lub teeb yuag, nqa tau yooj yim, nrog lub roj teeb lub neej ntev, thiab tuaj yeem siv rau hauv ntau yam tsawg -qhov chaw siab tshaj kev ruaj ntseg.



2, Cov khoom siv

Cov khoom siv (ntxiv) ntawm cov khoom no yog tsim raws li qhia hauv qab no:

TSIS MUAJ	Lub npe	Ntau	Chav tsev	Sau ntawv
1	Detection host	1	ib daim
2	Tsawg zaus kav hlau txais xov	1	ib daim
3	Full band kav hlau txais xov	1	ib daim
4	Fais fab adapter & them cable	1	ib daim
5	Lub thawv tiv thaiv	1	ib daim
6	European txheem conversion plug	1	ib daim



3, Muaj nuj nqi

1) Drone positioning^[1]:Nrhiav cov drones thiab qhia cov txiaj ntsig raws li cov cim ntawm drones ntawm e- daim ntawv qhia.

2) Pilot positioning^[2]:Nrhiav cov chaw taws teeb tswj (pilots), thiab qhia cov txiaj ntsig raws li cov cim ntawm cov chaw taws teeb tswj ntawm e- daim ntawv qhia.

3) FPV nrhiav pom:muaj peev xwm txheeb xyuas thiab txheeb xyuas cov kev sib tw hauv tsev drones, tiag tiag - lub sijhawm tsom xam ntawm lawv thawj - tus neeg caij dav hlau footage.

4) Pilot navigation^[4]: AAT-H2L-D Pro Pro npaj txoj hauv kev rau kev taug qab drone controllers nrog kev ua haujlwm yooj yim.

5) RID nrhiav pom^[5]:AAT-H2L-D Pro Pro tuaj yeem txheeb xyuas DJI drones (nrog OcuSync raws tu qauv), drones nrog RID, thiab tus lej cim tshwj xeeb (SN) ntawm WIFI drones.

6) Cov ntaub ntawv nthuav dav^[6]:Realtime zaub ntawm tus qauv drone, kev tswj xyuas, kev tshaj tawm, qhov siab, kev tswj xyuas tus tsav thiab lwm yam.

7) Cov npe dub thiab dawb^[7]:Thaum daim ntawv teev npe dawb tau teeb tsa, lub tswb ntawm AAT-H2L-D Pro Pro yuav tsis raug teeb tsa yog tias kuaj pom lub drone hauv daim ntawv dawb.

8) Kev ceeb toom ntxov:Lub cuab yeej yuav tswb los ntawm beeping lossis vibrating thaum pom lub drone.

9) Kev sib tw ua si:Pab cov neeg ua haujlwm ruaj ntseg los txheeb xyuas cov ntaub ntawv keeb kwm drone ya davhlau.

10) Cov ntaub ntawv keeb kwm:Cov txiaj ntsig tshawb pom yuav raug cawm rau kev tshuaj xyuas, suav nrog SN, qauv, zaus band, thiab lwm yam.

11) Ntau hom lus:Txhawb Askiv, Suav, Lavxias, thiab Portuguese.

Sau ntawv

[1]-[7]: Tsuas yog siv rau DJI series nrog OcuSync raws tu qauv.

[5]: GB 42590-2023, ASTM F3411 Chaw Taws Teeb ID, ASD-STAN prEN 4709-002.

4, Nta

1) Kev sib tw drone nrhiav pom:Tshiab hloov tshiab qis -frequency FPV nrhiav kom tau, uas tuaj yeem npog cov zaus bands ntawm feem ntau hauv tsev sib tw drones.

2) Duab demodulation:Tiag - lub sij hawm parsing thawj - neeg saib (FPV) footage ntawm FPV drones, nrog clearer duab demodulation.

3) Portable thiab yooj yim siv:Thaum kuaj pom thiab tso cov drones xws li DJI thiab Autel, cov cuab yeej no tuaj yeem ua haujlwm ib txwm tsis muaj lub kav hlau txais xov sab nraud, ua rau nws nqa tau ntau dua thiab cov neeg siv - tus phooj ywg.

4) Kev tswj hwm kev nyab xeeb:Muaj peev xwm ntes tau tshaj 900 hom drones, suav nrog DJI (xws li O4), Autel, Feimi, thiab lwm yam.

5) Kev sib txuas thiab kev sib txuas:tuaj yeem txuas mus rau qhov qis- qhov chaw tswj hwm qhov siab kom paub txog ntau- cov khoom sib txuas thiab ntse sib koom ua ke kev tswj hwm thaj chaw nyab xeeb.

6) Mobile thiab portable:Cov cuab yeej hnyav tsuas yog ~ 658g, yog portable rau cov tub rog ib leeg, thiab tuaj yeem siv tau tam sim tom qab qhib.



5, Parameter

5.1 Performance Index

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Ntau zaus	100MHz-6GHz
2	Tshawb nrhiav lub vojvoog	1 ~ 2km (ib puag ncig hauv nroog) 2 ~ 3km (qhib ib puag ncig)
3	Teb sijhawm	3 ~ 5s
4	Hom phiaj ntau	1 ~ 2km (ib puag ncig hauv nroog) 2 ~ 3km (qhib ib puag ncig)
5	Kev kuaj kom muaj nuj nqis	Ntau tshaj los yog sib npaug rau 10



 5.2 Mechanical Parameters

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Qhov ntev	185mm * 80mm * 33mm
2	Qhov hnyav	(658±10)g	Nrog tus kav hlau txais xov
3	Ntim lub thawv loj	L * W * H: (335 * 260 * 130mm) ± 5mm
4	Packing box hnyav (tag nrho)	2.5 kg ib



 5.3 Cov yam ntxwv ntawm hluav taws xob

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Roj teeb muaj peev xwm	8000 mAh	Ua - hauv lithium roj teeb
2	Lub sijhawm ua haujlwm	-4h	Thaum Screen brightness yog 20%, kub yog 25 degree
3	Lub sijhawm them nyiaj	~2.5 h	Nrog tus thawj charger



  5.4 Environmental Adaptability

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Ua haujlwm kub	-35 ~ 50 degree
2	Cia kub	-40 ~ 40 degree

  5.5 Kov Screen

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Screen loj	6-nti
2	Screen daws teeb meem	2160 * 1080 pixels kev daws teeb meem



 5.6 System Storage

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Nco	8gb ua
2	Cia	256 GB ua



  5.7 Kev ua haujlwm ib puag ncig

TSIS MUAJ	Qhov taw qhia	Parameter	Sau ntawv
1	Kev khiav hauj lwm qhov system	Android 12
2	Network ib puag ncig	Online / Offline
